| IP Video Input |
64-ch |
|
| Incoming Bandwidth |
400 Mbps |
|
| Outgoing Bandwidth |
400 Mbps |
|
| HDMI 1 Output |
8K (7680 × 4320)/30Hz, 4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 ×
1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 ×
720/60Hz, 1024 × 768/60Hz |
|
| HDMI 2 Output |
4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 ×
1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
*: When HDMI 1 output resolution is 8K, the maximum HDMI 2 output resolution is
1080p |
|
| VGA 1 Output |
1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
|
| VGA 2 Output |
1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
|
| Video Output Mode |
HDMI 1 and VGA 1 provide simultaneous video output, and work as the main output;
HDMI 2 and VGA 2 provide simultaneous video output, and work as the auxiliary output |
|
| CVBS Output |
1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480 |
|
| Audio Output |
2-ch, RCA (Linear, 1 KΩ) |
|
| Two-Way Audio |
1-ch, RCA (2.0 Vp-p, 1 KΩ, using the audio input) |
|
| Decoding Format |
H.265+/H.265/H.264+/H.264 |
|
| Recording Resolution |
32 MP/24 MP/12 MP/8 MP/7 MP/6 MP/5 MP/4 MP/3
MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
|
| Synchronous playback |
16-ch |
|
| Decoding Capability |
2-ch@32 MP (30 fps) + 2-ch@8 MP (30 fps)/10-ch@8 MP (30 fps)/20-ch@4 MP (30
fps)/40-ch@1080p (30 fps |
|
| Audio Compression |
G.711ulaw/G.711alaw/G.722/G.726/AAC/MP2L2/PCM |
|
| Network Protocol |
TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP,
UPnP™, HTTP, HTTPS, UDP, RTP, RTCP |
|
| Network Interface |
2, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface |
| RAID Type |
RAID0, RAID1, RAID5, RAID6, RAID10 |
|
| Serial Interface |
1 RS-485 (full-duplex), 1 RS-232 |
|
| SATA |
8 SATA interfaces supporting hot-plug |
|
| eSATA |
1 eSATA interface |
|
| Alarm In/Out |
16/9 |
|
| Capacity |
Up to 16 TB capacity for each disk |
|
| USB Interface |
Front panel: 2 × USB 2.0; Rear panel: 2 × USB 3.0 |
|
| Power Supply |
100 to 240 VAC, 50 to 60 Hz |
|
| Consumption |
≤ 50 W (without HDD) |
|
| Dimension (W × D × H) |
445 × 465 × 93 mm ( 17.5″× 18.3″ × 3.7″) |
|
| Weight |
≤ 10 kg (22 lb) |
|
| Obtained Certification |
CE, FCC |
|
| FCC |
Part 15 Subpart B, ANSI C63.4-2014 |
|
| CE |
EN 55032:2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4 |
