| Image Sensor |
1/3" Progressive Scan CMOS |
| Max Resolution |
3072 × 1728 (5MP) |
| Shutter Time |
1/3 s to 1/100,000 s |
| Minimum Illumination |
Color: 0.005 Lux @ F1.6 (AGC ON), B/W: 0 Lux with IR |
| Day/Night |
IR Cut Filter |
| Angle Adjustment |
Pan: 0° to 360°, Tilt: 0° to 75°, Rotate: 0° to 360° |
| Lens Type |
2.8mm Fixed Lens |
| Aperture |
F1.6 |
| Horizontal FOV |
98° |
| Vertical FOV |
54° |
| Diagonal FOV |
114° |
| DORI Distance |
Detect: 63m, Observe: 25m, Recognize: 12m, Identify: 6m |
| Supplement Light Type |
IR + White Light |
| IR Distance |
Up to 30m |
| White Light Distance |
Up to 20m |
| Smart Supplement Light |
Yes |
| IR Wavelength |
850nm |
| Main Stream |
20fps @ 3072×1728, 25fps @ 1080P/720P (50Hz), 24fps @ 1080P/720P (60Hz) |
| Sub Stream |
Up to 25fps (50Hz), Up to 24fps (60Hz) |
| Video Compression |
H.265+ / H.265 / H.264+ / H.264 |
| Video Bit Rate |
32 Kbps to 8 Mbps |
| Bit Rate Control |
CBR / VBR |
| ROI |
1 Fixed Region |
| Audio |
Built-in Microphone & Speaker |
| Two-Way Audio |
Yes |
| Audio Compression |
G.711ulaw / G.711alaw / G.722.1 / G.726 / MP2L2 / PCM / AAC-LC |
| Audio Sampling Rate |
8 kHz / 16 kHz |
| WDR |
120 dB True WDR |
| SNR |
≥ 52 dB |
| Day/Night Switch |
Day / Night / Auto / Schedule |
| Image Enhancement |
BLC, HLC, 3D DNR |
| Privacy Mask |
4 Programmable Areas |
| Ethernet Interface |
1 × RJ45 10/100M Ethernet Port |
| On-board Storage |
MicroSD Slot, up to 512GB |
| Reset Button |
Yes |
| Simultaneous Live View |
Up to 6 Channels |
| User Access |
Up to 32 Users |
| API |
ONVIF Profile S/T/G, ISAPI, SDK |
| Protocols |
TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP |
| Basic Events |
Motion Detection, Video Tampering Alarm, Exception |
| Alarm Actions |
FTP Upload, SD Card Storage, Email, Surveillance Center Notification, Recording, Snapshot |
| Power Supply |
12VDC ±25% or PoE (IEEE 802.3af) |
| Power Consumption |
Max. 5W (DC), Max. 6.5W (PoE) |
| Material |
Metal |
| Protection Rating |
IP67 |
| Dimensions |
Ø127.3 × 96.3 mm (Ø5" × 3.8") |
| Weight |
Approx. 590g |
| Package Weight |
Approx. 830g |
| Operating Temperature |
-30°C to 60°C (-22°F to 140°F) |
| Operating Humidity |
≤95% (Non-condensing) |
| Certifications |
FCC, CE, UL, RoHS, WEEE, REACH |
| General Functions |
Heartbeat, Anti-banding, Mirror, Password Protection, Password Reset via Email |
