| Image Sensor |
1/2.4" Progressive Scan CMOS |
| Max Resolution |
3840 × 2160 (8MP) |
| Minimum Illumination |
Color: 0.005 Lux @ F1.6 (AGC ON), B/W: 0 Lux with IR |
| Shutter Time |
1/3 s to 1/100,000 s |
| Day/Night |
IR Cut Filter |
| Angle Adjustment |
Pan: 0°~360°, Tilt: 0°~75°, Rotate: 0°~360° |
| Lens Type |
2.8mm Fixed Lens |
| Aperture |
F1.6 |
| Horizontal FOV |
105° |
| Vertical FOV |
55° |
| Diagonal FOV |
127° |
| DORI Distance |
Detect: 76m, Observe: 30m, Recognize: 15m, Identify: 7m |
| Supplement Light Type |
IR + White Light |
| Supplement Light Range |
Up to 30m |
| Smart Supplement Light |
Yes |
| IR Wavelength |
850nm |
| Main Stream |
15fps @ 3840×2160, 20fps @ 3200×1800 / 2688×1520 / 1080P / 720P |
| Sub Stream |
Up to 20fps @ 720P / VGA |
| Video Compression |
H.265+ / H.265 / H.264+ / H.264 |
| Video Bit Rate |
32 Kbps to 16 Mbps |
| Bit Rate Control |
CBR / VBR |
| ROI |
1 Fixed Region |
| Audio |
Built-in Microphone & Speaker |
| Two-Way Audio |
Yes |
| Audio Compression |
G.711 / G.722.1 / G.726 / MP2L2 / PCM / AAC-LC |
| Audio Sampling Rate |
8 kHz / 16 kHz |
| WDR |
120 dB True WDR |
| SNR |
≥ 52 dB |
| Day/Night Switch |
Day / Night / Auto / Schedule |
| Image Enhancement |
BLC, HLC, 3D DNR |
| Privacy Mask |
4 Programmable Areas |
| Ethernet Interface |
1 × RJ45 10/100M Ethernet Port |
| On-board Storage |
MicroSD Slot, up to 512GB |
| Built-in Microphone |
Yes |
| Built-in Speaker |
Yes (95 dB @ 10cm) |
| Reset Button |
Yes |
| Simultaneous Live View |
Up to 6 Channels |
| User Access |
Up to 32 Users |
| API |
ONVIF Profile S/T/G, ISAPI, SDK |
| Protocols |
TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP, UPnP |
| Basic Events |
Human & Vehicle Motion Detection, Video Tampering Alarm, Exception |
| Alarm Actions |
FTP/NAS Upload, Email, Recording, Snapshot, Audible Warning, Flashing Light |
| Flashing Light |
Red & Blue Active Deterrence Light |
| Power Supply |
12VDC ±25% or PoE IEEE 802.3af |
| Power Consumption |
Max. 8W (DC), Max. 9.5W (PoE) |
| Material |
Metal & Plastic |
| Protection Rating |
IP67 |
| Dimensions |
Ø127.3 × 96.3 mm (Ø5" × 3.8") |
| Weight |
Approx. 590g |
| Package Weight |
Approx. 830g |
| Operating Temperature |
-30°C to 60°C (-22°F to 140°F) |
| Operating Humidity |
≤95% (Non-condensing) |
| Certifications |
CE, UL, RCM, RoHS, WEEE, REACH, IP67 |
| General Functions |
Heartbeat, Anti-banding, Mirror, Password Protection, Password Reset via Email |
